Inovance MD605A MD605A-4T9R5B Compact AC Drive 4 kW 380 to 480 V 3-Phase CAN Built-in Braking Unit

Product Description

The Inovance MD605A-4T9R5B is a compact general-purpose AC drive for three-phase 380 to 480 V motors, rated 4 kW in the T2 housing with a built-in braking unit. It combines open-loop sensorless vector control for asynchronous and synchronous motors with standard Modbus-RTU communication and CANopen or CANlink networking through dual RJ45 ports, making it suitable for small automation equipment that needs bus-based axis monitoring.

Standard Features

• Compact housing: 38% smaller volume than the previous generation, with vapour chamber cooling and a separate air duct.
• Integrated control: One drive handles asynchronous and synchronous motors with open-loop sensorless vector control (SVC).
• Dual network ports: CN1 and CN2 RJ45 ports support CANopen and CANlink for daisy-chain networking.
• Crimp terminals: Tool-free push-in terminals shorten wiring and commissioning time.
• Reliability: Conformal coating on the driver board, intelligent fan control, stall protection and slip start.
• Built-in braking unit: Supports controlled deceleration without an external braking module.
• Larger frame: T2 housing gives more thermal headroom for continuous duty.
