Siemens 3RT6023-1BB40

Altivar Soft Starter ATS480 is designed to start and stop asynchronous motors supplied from 208V to 690V. It meets the demanding requirements of both normal and heavy-duty applications, making it ideal for industrial processes, infrastructures, and machinery.

Performance Features

• Operational Rated Current: 17A (normal duty)

• Motor Power Range: 4kW to 15kW (depending on mains voltage)

• Torque Control System (TCS): Ensures smooth acceleration and deceleration

• Dynamic Braking & DC Injection: Efficiently stops high-inertia applications

• Connection Options: Can be connected in-line or inside the delta to reduce operational current

• Embedded Test Routine: Simplifies commissioning when connected inside the delta

Digital & Cybersecurity Features

• Optimized for connected systems and digitization

• Designed to meet cybersecurity standards

• Simplifies project execution and maximizes application availability

Compatibility & Accessories

• Shared Features with Altivar Drives: Display terminals, remote mounting kits, and communication modules

• Compatible with ATS48: Same footprint, fixing points, torque control algorithm, I/O, and menus

• Common Accessories: Line chokes, DNV kits

EcoStruxure Integration

• Integrated with EcoStruxure platform

• Drastically simplifies architecture selection, detailed design, and execution in automation and electrical systems

Dimensions & Weight

• Dimensions: 160 mm (width) x 203 mm (depth) x 275 mm (height)

• Weight: 4.9 kg

Certifications

• Conforms to IEC/EN 60947-4-1

• Certified CE, cULus, UKCA, CCC, RCM, EAC

• Marine certified: DNV, ABS, BV, and CCS

Environmental Compliance

• Green Premium product

• Compliant with RoHS and REACH standards

• Designed with sustainability in mind, exceeding current environmental directives and regulations
