Contattore Schneider Electric LC1D38M7C TeSys D – 38 A, 3 poli, 18,5 kW a 400 V (AC-3)

Produttore: Schneider Electric
Modello: LC1D38M7C
Tipo: TeSys Deca Contactor
Corrente nominale: 38 A (AC-3 @ ≤ 440 V)
Potenza del motore: 18.5 kW @ 400 V AC
Tensione della bobina: 220 V CA, 50/60 Hz
Contatti ausiliari: 1 NO + 1 NC

Descrizione del prodotto

The Schneider Electric LC1D38M7C is a 3-pole TeSys Deca contactor designed for motor control and resistive load switching in industrial, HVAC, and building automation applications. It is rated 38 A in AC-3/AC-3e category at voltages up to 440 V AC, corresponding to a motor power of 18.5 kW at 380–400 V AC and 9 kW at 220–230 V AC. The contactor features a 220 V AC 50/60 Hz control coil and comes with 1 NO + 1 NC built-in auxiliary contacts, with the NC contact mirror-certified per IEC 60947-4-1. Connection is made via screw clamp terminals. The compact 45 mm wide design supports DIN-rail or screw mounting, making it suitable for space-constrained panels. It is rated for operating rates up to 3,600 cycles/hour at 60 °C and offers a mechanical service life of 15 million operating cycles.

Caratteristiche standard

  • 38 A / 18.5 kW AC-3 Rating: Rated operational current of 38 A in AC-3/AC-3e category at ≤ 440 V AC, suitable for direct-on-line starting of three-phase motors up to 18.5 kW at 380–400 V AC.
  • 220 V AC 50/60 Hz Coil: Standard AC control coil voltage for integration with common industrial control circuits.
  • Built-in 1 NO + 1 NC Auxiliary Contacts: Provides integrated signal contacts for status feedback and interlocking, with NC mirror certification per IEC 60947-4-1.
  • Compact 45 mm Width: Space-saving design enables DIN-rail mounting or screw fixing, optimizing panel layout in space-constrained enclosures.
  • High Operating Rate: Rated for up to 3,600 cycles/hour at 60 °C, suitable for frequent switching applications in demanding industrial environments.
  • Extended Mechanical Durability: Mechanical service life of 15 million operating cycles ensures long-term reliability in high-cycle applications.
  • Multi-Standard & Green Premium: Certified to IEC, UL, CSA, CCC, EAC, and Marine standards; Green Premium compliant (RoHS/REACh), with a total lifecycle carbon footprint of 311 kg CO₂ eq.

Specifiche tecniche

ParametroValore
ProduttoreSchneider Electric
ModelloLC1D38M7C
SerieTeSys Deca / TeSys D
Tipo di prodottoContattore
Rated Operational Current (Ie) – AC-338 A (at <60 °C, ≤ 440 V AC)
Rated Operational Current (Ie) – AC-150 A (at <60 °C, ≤ 440 V AC)
Motor Power (AC-3 @ 380–400 V)18,5 kW
Motor Power (AC-3 @ 220–230 V)9 kW
Tensione di controllo della bobina220 V CA, 50/60 Hz
Contatti ausiliari1 NO + 1 NC (certificazione specchio NC)
Tensione operativa nominale (Ue)≤ 690 V AC (25–400 Hz) / ≤ 300 V DC
Tensione nominale di isolamento (Ui)690 V (IEC 60947-4-1)
Tensione nominale di tenuta all'impulso (Uimp)6 kV
Tipo di connessioneTerminali a morsetto a vite
Dimensioni (L × A × P)45 mm × 85 mm × 92 mm
Peso netto0.38 kg
Grado di protezioneIP20 (frontale)
Temperatura di esercizio−40 to +60 °C (up to +70 °C with derating)
Standard e certificazioniIEC 60947-4-1, UL, CSA, CCC, EAC, Marine; Green Premium (RoHS/REACh)
